    1000-31B

    The Val-Tex 1000-31B is a rugged, light weight screw prime unit that can be used in any position. The 1000-31B comes complete with dual swivel hose and coupler.

    Delivery: 1 oz./ 15 strokes
    Weight: 13 lbs.
    Lube Sealant Size: K

    Viper 300dpi

    Less work, Faster results!

    The VIPER® is a new type of manual lubrication gun only offered by Val-Tex. This rugged, light weight foot pump is portable and allows for hands free operation. A typical hand-held, screw prime grease gun takes over 10 minutes to inject a K stick while the VIPER®  can deliver an K stick in less than 2 minutes with MUCH less effort.  Also, the VIPER®  will build pressure extremely quickly  (6,000 PSI in only 4 strokes) making it very easy to fully charge the valve with stick grease.



    WHY DO YOU WANT A VIPER® ?

    • 5 TIMES FASTER THAN A TYPICAL HAND-HELD SCREW PRIME GREASE GUN

    • BUILD 6,000 PSI IN ONLY 4 STROKES

    • PUMPS AN ENTIRE “K” STICK IN ONLY 118 STROKES

    • FOOT PUMP ALLOWS HANDS FREE OPERATION

    • LIGHT AND PORTABLE

    • INTEGRATED CAP GAUGE FOR SAFETY

    • OPTIONS

    • K OR J SIZE BARREL

    • 6 FOOT OR 10 FOOT HOSE



    QS-5000-CPneumatic/Hydraulic Lubrication Unit

    • Large 5 lb. Capacity FAST Injection!
    • Detachable Cylinder for Easy Loading and Unloading by One Person

    Compare the efficiency of pumping 8 ounces of material using:

    • A hand held hydraulic gun: 350 strokes

    • The QS-5000-C: As little as 30 seconds

    • The Val-Tex QS-5000-C allows you to save time and money on valve maintenance
    The Val-Tex QS-5000-C is a fast, compact, and rugged lubrication unit that pumps 8 ounces of material in 30 to 60 seconds.  With only 20 CFM at 100 PSI input pressure, the pump will produce up to 10,000 PSI.

    The QS-5000-C weighs 156 lbs. and holds either a 5 lb. “V” size lube sealant sticks, a 4 lb. “P-4” “lube packs, or Valve Flush.  It comes standard with a durable metal reservoir for added protection.  The frame is made of solid steel for additional toughness.

    The QS-5000-C comes complete with a ten foot, 3/8” I.D. high pressure sealant hose, 15,000 PSI 2-1/2” liquid filled gauge, Gauge Guard, dual swivels, bleeder valve and a giant button head coupler.

    This unit is ideal for busy iron shops to dramatically increase the number of valves lubricated per day with the stick material recommended by the manufacturer.



    Delivery: 8 oz./ 30-60 seconds
    Weight: 153 lbs.
    Lube Sealant Size: V, P-4, VF-GAL
    PSI Rating: 10,000
    Dimensions: 46″ H x 20″ W x 26″ L
    CFM Required: 20
    Air Pressure Required: 75-100 PSI

    Viper ball valve field

    FOR API GATE VALVE BODY FILL ONLY

    A practical gun for servicing gate valve bodies. The reversible pail adaptor provides uninterrupted flow. The swing type dolly mounted on rubber tired wheels keeps the container upright at all times. The enclosed sealant canister keeps dirt and foreign materials out. Heavy duty latches keep the lid secure.

    NOTE: Never use a bulk grease to service high pressure plug and ball valves. Stick grease is required per the manufacturer.

    Delivery: 1-16 ounces per stroke
    Weight: 78 lbs.
    Lube Sealant Size: 5 gal. / 40 lp. pail
    PSI Rating: 8,000
    Dimensions: 37″ H x 19″ W x 24″ L

    QS-2000A with 2010 package

    LUBRICATOR, SEPARATOR, REGULATOR, PACKAGE

    The most common issue with the QS-2000A is damage to the Enerpac pump due to dirty or  wet air.  A re-kit and repair of this problem is $300-$400 not including the cost of downtime, freight, and aggravation.  Part number 2010 Regulator, Separator and Lubricator package will dramatically extend the life of the hydraulic pump and reduce downtime, contact Farley Riggs for all enquiries.

    Part number 2010 Regulator, Separator and Lubricator package comes complete with bracket, hardware, air fittings, and tubing. We will install it on a new unit at no charge if both are ordered at the same time.  It can also be installed easily by the operator with the use of simple hand tools.
